Sundown Audio 10″ 2-Ohm 2000 Watts RMS M Series Subwoofer – M10D2

Description

• Unmatched Sound Quality: Feel every beat and bass drop with deep, accurate, and impactful sound.
• Exceptional Power Handling: Boasting a robust 2000 Watts RMS, this subwoofer is ready to handle the most demanding tracks.
• Durability & Longevity: Built with rugged construction to withstand intense use and deliver consistent performance.

Sundown Audio 10″ 2-Ohm 2000 Watts RMS M Series Subwoofer – M10D2

This Listings Includes:

• (1) Sundown Audio Series M Subwoofer 10 inch, 2000 Watts RMS, 2-Ohm

Be the first to Unleash the power of superior bass with Sundown Audio M Subwoofers. Crafted for audio enthusiasts who demand the best, the M series delivers deep, punchy, and precise bass that enhances any car audio setup. Featuring innovative technology, high-quality materials, and durable construction, these subwoofers offer outstanding power handling and longevity. Perfect for both upgrades and custom installations, Sundown Audio M Subwoofers ensure exceptional sound quality and performance. Explore our range of M series subwoofers and take your audio experience to the next level with Sundown Audio.

Technical Specifications:

• Nominal Diameter: 10″ / 254mm
• Nominal Impedance: Dual 2-Ohm
• RMS Power Handling: 2000W
• MAX Power Handling: 4000W
• Sensitivity (1w/1m): 79.14dB
• Voice Coil Diameter: 3″ / 76.2mm, 4-layer aluminum round wire
• Basket Material: Custom Tooling Cast Aluminum
• Magnet Weight: Quad Stack, 200mm Diameter x 88mm Stack Height
• Motor Venting: Vented pole & backplate, frame-integrated cooling
• Top Plate Thickness: 20mm

Thiele/Small Parameters:

• Re (DC Resistance): 4.19 Ohm
• Fs (Resonant Frequency): 37.736 Hz
• Vas (Equivalent Compliance Volume): 7.793 Liters
• Qes (Electrical Q): 0.761
• Qms (Mechanical Q): 4.847
• Qts (Total Q): 0.658
• Le (Inductance): 3.682 mH
• BL (Motor Force): 23.82
• Mms (Moving Mass): 434.5335 g
• Cms (Suspension Compliance): 40.935 uM/N
• Xmax (One-Way Linear Excursion): 35mm

Physical Dimensions:

• Mounting Depth: 10.09″
• Overall Diameter: 11.65″
• Cut-Out Diameter: 10.01″
• Displacement: 0.2 cu ft
