DS18 GFX Series Monoblock 3000 Watt 2 Ohm Class D Full range Amplifier GFX-3K2

Description

DS18 GFX Series Monoblock 3000 Watt 2 Ohm Class D Full range Amplifier GFX-3K2

The DS18 GFX Series of amps are for the enthusiast that is serious about squeezing every watt possible out of your sound system for a concert hall type of sound that can be heard for miles away!

This Listing Includes:

(1) Amplifier

Features:

– Full range Capable Class – D Amp

– Compact Size and wide Band Crossover for more applications

– Variable Full Crossover Filter

– Surface Mount Component

– Audio Precision Quality Control Verification

– Stable & Reliable Four Layers PCB Trace Layout

– Heavy Duty Heat-sink Chassis and Forced Cooling System Build In

Specifications:

Model – GFX-3K2

Power @ 2 ohms (14.4V) – 3000W

Power @ 4 ohms (14.4V) – 2000W

Minimum Speaker Load – 2 OHM

THD – 1%

Input Sensitivity – 0.5-8V

Hi Pass Crossover (12dB/Oct) – 15Hz-2KHZ

Lo Pass Crossover (12dB/Oct) – 50Hz-20KHZ

Frequency Response – 15Hz-20KHZ

Bass Boost – 0-12dB

Bass Boost Frequency – 35Hz-70Hz

Working Voltage – 9-15V

Input Terminal Size – 1/0AWG

Output Terminal Size – 8 AWG

Dimensions:

211 x 236 x 72
