Description
- Mind-Blowing Bass – The ZR8.4D is a powerhouse with 900W MAX and 450W RMS power handling, delivering a spine-tingling audio experience that will leave you craving more.
- Precision Performance – With a 2-inch high-strength aluminum voice coil, this subwoofer ensures every note is delivered with precision and clarity, elevating your car audio system to new heights.
- Dual Voice Coil Configuration – The 4+4 ohm dual voice coil configuration allows matching your amplifier’s optimal impedance for maximum power transfer and efficiency.
- Unmatched Style – Featuring a strong stamped basket and show-quality DS18 logos, the ZR8.4D adds elegance with its matte black finish, making it visually stunning in any car audio setup.
- Exceptional Durability – Renowned for exceptional performance, this subwoofer not only delivers outstanding sound but also boasts unbreakable durability.
DS18 8″ Elite Series 900 Watts Dual Voice Coil 4 Ohm Subwoofer ZR8.4D
This listing includes:
- (1) Elite-Z 8 Inch 1000W Dual 4 Ohm Voice Coil Car Audio Subwoofer
Introducing the DS18 ZR8.4D, an 8″ Subwoofer designed to redefine your car audio experience. With a robust 900W MAX and 450W RMS power handling, this powerhouse delivers mind-blowing bass and precision performance. The 2-inch high-strength aluminum voice coil ensures every note is delivered with clarity, taking your audio system to new heights. The 4+4 ohm dual voice coil configuration allows optimal impedance matching, maximizing power transfer and efficiency. Beyond performance, the ZR8.4D features a stamped basket, show-quality DS18 logos, and a matte black finish, adding an element of elegance to your car audio setup.
Features:
- 900W MAX / 450W RMS Power Handling
- 2-inch High-Strength Aluminum Voice Coil for Precision
- Dual 4+4 ohm Voice Coil Configuration
- Stamped Basket with DS18 Logos for Structural Integrity
- Matte Black Finish for Visual Elegance
SPECIFICATIONS:
- Nominal Diameter: 8″ / 203.3mm
- Nominal Impedance: 4 + 4 Ohm
- RMS Power Handling: 450W
- Maximum Power Handling: 900W
- Sensitivity (1w/1m): 82 dB
- Frequency Response: 33-200Hz
- Recommended Lo Pass Crossover: 120Hz
- Voice Coil Diameter: 2″ / 50.8mm
- Voice Coil Former Material: Aluminum
- Winding Material: Copper
- Cone Material: Non-Pressed Paper
- Dust Cap Material: PPI
- Surround Material: Foam
- Basket Material: Steel
- Basket Color/Finish: Black Matte
- Magnet Material: Ferrite
- Magnet Weight: 55 Oz
- Displacement Volume: 0.03 ft3
- Equivalent Volume Vas: 5.33 L
- Excursion (one way) Xmax: 18mm
- Free Air Resonance Fs: 45Hz
- Mechanical Factor Qms: 4.7
- Electrical Factor Qes: 0.745
- Total Factor Qts: 0.643
- Moving Mass Mms: 97g
- Compliance Cms: 97.58? m/N
- Bl Factor BI: 9.48
- Voice Coil Inductance Le: 551.18m mH
- Diaphragm Area Sd: 196 Cm2
- DC Resistance Re: 3.4 + 3.4 Ohm
- Efficiency Bandwidth Product EBP: 60.4
DIMENSIONS:
- Overall Diameter: 8.42″
- Overall Depth: 5.3″
- Front Mount Baffle Cutout: 7.24″
- Mounting Depth: 4.4″
