DS18 1″ Aluminum VC 200W Max 4-Ohm High Compression Neodymium Bullet Tweeter

Description

• Extraordinary Power and Precision: Discover the extraordinary power and precision of DS18’s PRO-TW820, a high compression neodymium super bullet tweeter designed to redefine your sound system with its astonishing performance.
• Compact yet Powerful: Don’t be deceived by its compact size; the PRO-TW820 packs an astonishing punch with 200W of peak power handling, effortlessly outperforming any other tweeter in its class and delivering rich, clear, and undeniably loud sound.
• High Compression Design: Engineered for precision, the PRO-TW820 features a high compression design that ensures every detail of your audio is reproduced with accuracy and clarity, providing an immersive listening experience.
• Neodymium Magnet: Equipped with a neodymium magnet, the PRO-TW820 offers powerful sound reproduction in a compact package, perfect for enhancing your sound system with its superior performance.
• Adjustable Surface Mount: With an adjustable surface mount, the PRO-TW820 provides flexibility in installation, allowing you to customize the placement of the tweeter for optimal sound performance.

DS18 1″ Aluminum VC 200W Max 4-Ohm High Compression Neodymium Bullet Tweeter

This Listing includes:

• (1) 200W 4-Ohm High Compression Tweeter
• (1) 3.3uF Capacitor

Experience the extraordinary power and precision of DS18’s PRO-TW820 2.3″ Neodymium Super Bullet Tweeter. Engineered to redefine your sound system, the PRO-TW820 delivers astonishing performance in a compact package. With 200W of peak power handling, this tweeter packs an astonishing punch that effortlessly outperforms any other tweeter in its class, delivering rich, clear, and undeniably loud sound that will redefine your listening experience.

Features:

• High compression neodymium super bullet tweeter design
• 200W peak power handling for powerful sound reproduction
• Compact size with exceptional performance
• Neodymium magnet for superior sound quality
• Adjustable surface mount for flexible installation

Technical Specifications:

• Nominal Diameter: 2.3″
• Nominal Impedance: 4 Ohm
• AES Power Handling: 50W
• Program Power Handling: 100W
• Peak Power Handling: 200W
• Sensitivity (1w/1m): 105dB
• Frequency Response: 2Khz-20Khz
• Recommended Hi Pass Crossover: 3KHz
• Voice Coil Diameter: 1″ / 25.4mm
• Diaphragm Material: Aluminum
• Magnet Material: Neodymium
• Body Material: Aluminum

Measurements:

• Overall Diameter: 2.28″ / 58mm
• Overall Depth: 2.67″ / 68mm
• Front Mount Baffle Cutout: 1.69″ / 43mm
• Mounting Depth 1.65 – 2.55″ / 42 – 65mm
