Description
- Impressive 12,000W RMS Output @ 1 Ohm Delivers extreme power for SPL and demo builds with dynamic output up to 14,000W.
- Advanced HVAC Thermal Management Internal fan and smart heatsink design keep the amp cool under high stress.
- ZVL-Ready for Multi-Amp Systems Easily sync multiple Z-Series amps with the ZVL linking module.
- Remote Bass Knob with LCD Display Monitor voltage and clipping in real time for full control from the drivers seat.
- Heavy-Duty Quad Power Terminals Accepts 4x 0 AWG inputs for maximum current flow and system stability.
This Listing Includes:
- (1) DD Audio Z12000 1-Channel Monoblock Subwoofer Amplifier
- (1) Remote Bass Level Control with LCD Voltage Display and Clipping Indicator
Product Overview:
The Z12000 is the latest evolution in DD Audios elite Z Seriesa legacy line of powerhouse amplifiers built for competitive SPL and extreme demo systems. Engineered for raw performance, this monoblock Class D half-bridge amp delivers 12,000W RMS at 1 Ohm, with peak dynamic output reaching up to 14,000 watts. Optimized for 16V electrical systems, it’s the ultimate weapon for serious bass heads looking to break barriers.
Despite its insane output, the Z12000 features a surprisingly compact footprint, allowing dual wide installation in many modern SPL and demo vehicles. At its core is DD Audios advanced HVAC thermal management system, combining a heavy-duty extruded aluminum heatsink, smart fin design, and an internal brushless cooling fan that pulls fresh air through elevated vents to keep internal components cool during extreme use.
For advanced system setups, the Z12000 is ZVL-ready, making it easy to integrate multiple amps into your build with perfect synchronization. Whether you’re chasing SPL trophies or just shaking the streets, this amp is designed to deliver unmatched power and precision with rock-solid stability.
Power Output:
- 4000W RMS @ 4 Ohm
- 7000W RMS @ 2 Ohm
- 12,000W RMS @ 1 Ohm
- 14,000W Peak Dynamic Output
Key Features:
- Optimized for 16V Electrical Systems
- High-Current Half-Bridge Design
- Advanced HVAC Heat Management System
- ZVL Module Compatible for multi-amp linking
- Variable 24dB/Octave Subsonic & Low-Pass Filters
- 5-Way Protection Circuitry: Thermal, Overload, Short, Voltage, and Clipping
- Remote Bass Knob with LCD Voltage Display & Clip Indicator
- Quad Power Input Terminals for Maximum Current Flow
- Heavy-Duty Black Anodized Z-Style Heatsink
Specifications:
- Operating Voltage: 9V 16V
- Test Voltage: 14.4V
- Input Sensitivity: 0.2V 8V
- S/N Ratio: > 92 dB
- Damping Factor: > 200
- Frequency Response: 10Hz 200Hz
- High Pass Filter: 10Hz 50Hz
- Low Pass Filter: 20Hz 200Hz
- Power Wire Input: 4x 0 AWG
- Speaker Wire Input: 4x 8 AWG
- Dimensions (in): 27″ x 12″ x 3.125″
- Dimensions (mm): 686 x 305 x 83
- Max Current Draw: 1200A
Built for Bass That Breaks Limits
Designed for high-output, high-demand builds, the DD Audio Z12000 delivers the kind of power that redefines whats possible in car audio. Compact, intelligent, and brutally strongthis is your next stage in SPL domination.
