American Bass 35Hz-400hz AB-3X Crossover Unmatched Precision for Superior Sound

Description

• American Bass Way Active Crossover: Precision audio control at its finest.
• Front High Pass (x1) and (x20) with ranges of 35Hz-400Hz and 700Hz-8Khz (-18dB/OCT) respectively.
• Rear High Pass covers 35Hz-400Hz, Subwoofer Low Pass ranges from 45Hz-250Hz (-18dB/OCT).
• Outputs Level: 8V Peak, Frequency Response: 10-50KHz (-3dB), S/N Ratio: 110dB, THD: 0.01%.

American Bass 35Hz-400hz AB-3X Crossover Unmatched Precision for Superior Sound

This listing includes:

• (1) AB-3x Crossover

Introducing the AB-3X Crossover by American Bass, the essential tool for unrivaled audio clarity and precision. Crafted for audiophiles, this crossover divides your music into distinct frequency bands, optimizing each speaker for its ideal range. The result is a harmonious blend of highs, mids, and lows that creates a richer, more immersive listening experience. The ABX 3.1A Crossover not only delivers exceptional audio quality but also boasts a sleek design and cutting-edge technology, showcasing American Bass’s dedication to superior sound innovation. Immerse yourself in the art of sound with the AB-3X Crossover.

Features:

• Precision-designed for audiophiles
• Divides music into distinct frequency bands
• Optimizes each speaker for ideal range
• Harmonious blend of highs, mids, and lows
• ABX 3.1A Crossover with sleek design and cutting-edge technology

Technical Specifications:

• Front High Pass (x1): 35Hz-400Hz | (x20): 700Hz-8KHz
• Rear High Pass: 35Hz-400Hz
• Subwoofer Low Pass/Frequency: 45Hz-250Hz (-18dB/Oct)
• Outputs Level: 8V Peak
• Frequency Response: 10-50KHz (-3dB)
• S/N Ratio: 110dB
• THD: 0.01%
• Input Impedance: 20K ohms
• Output Impedance: Less than 150 ohms
• Channel Separation: More than 70dB.
• Variable Subsonic Filter: On/Off with -18dB/Oct. at 40 Hz
