Description
- Massive 6000W Output Delivers 2000W at 4 Ohm, 4000W at 2 Ohm, and 6000W at 1 Ohm RMS for serious bass or pro audio builds.
- Quad Toroidal Power Supply Provides relentless current delivery with oversized capacitors for clean, stable power.
- Hybrid Full-Bridge Design Exclusive DD circuit combines full-bridge speed with high-current stability for big, clean output.
- Compact Yet Powerful Rugged 11.25″ 7.3″ 2.4″ aluminum chassis with enhanced heat sink and multiple vents for maximum cooling.
- Competition Ready Engineered for stunt walls, pro audio systems, and extreme bass builds with ultra-low noise and superior reliability.
6000 Watts RMS Full Range Compact Monoblock Class D Amplifier DD Audio SS6000
This Listing Includes
- (1) DD Audio SS6000 Monoblock Amplifier
- (1) Remote gain control
The DD Audio SS6000 is a state-of-the-art 6000W compact monoblock amplifier engineered for high-current, full-range performance. Built with DDs exclusive full-bridge hybrid circuit and quad toroidal power supply, the SS6000 delivers clean, powerful output with ultra-low distortion. Designed for both massive stunt wall systems and bass-heavy builds, this amplifier combines superior efficiency with robust cooling and DD Audios legendary reliability.
Features
- 6000W Max Output Class D, high-speed, high-current design
- Quad Toroidal Power Supply with oversized capacitors
- Full-bridge hybrid circuit for clean, full-range power
- Remote gain control included
- Heavyweight DD aluminum chassis with enhanced cooling
- Dual 0 AWG power terminals & set screw speaker terminals
- 12dB/Oct HPF (20Hz80Hz) & LPF (80Hz20kHz)
- Compact footprint with superior thermal performance
Specifications:
- Operating Voltage: 9V16V
- Test Voltage: 14.4V
- Input Channels: 2
- Output Channels: 1 (Monoblock)
- Power @ 4-Ohm: 2000W RMS
- Power @ 2-Ohm: 4000W RMS
- Power @ 1-Ohm: 6000W RMS
- Max Current Draw: 600A
- RCA Input Sensitivity: 4V-0.4V
- RCA Input S/N: >95dB
- Damping Factor: >100
- THD: <1.0%
- Frequency Response: 20Hz-20kHz
- Subsonic Filter: 20Hz-80Hz
- Low-Pass Filter: 80Hz-20kHz
- Power Wire Gauge: 0 AWG
- Speaker Wire Gauge: 4 AWG
- Pass Thru Output: No
- Remote Control: Included
Dimensions:
- Length: 11.25″ (286 mm)
- Width: 7.3″ (185 mm)
- Height: 2.4″ (60 mm)
