Description
- Max. 20fps@5MP
- Built-in mic
- Max. IR length 30m
- Smart IR: Support
- IR LEDs: 1
Dauha OEM 5MP IR In/Outdoor Eyeball 2.8mm Fixed Lens CCTV Security Camera CVI
The Dauha 5MP HD eyeball security camera is a high-quality affordable solution to your home or business surveillance needs. It has an IP67 rating and is 100% protected against solid objects like dust and sand, and it has been tested to work for at least 30 minutes while under 15cm to 1m of water, so it can be used indoors or outdoors. The white color blends in nicely to many applications and can also see 98 feet at night with InfraRed technology. The built-in mic allows the camera to capture audio so you can hear as well as see what is happening.
This Listing Includes:
(1) Eyeball Security Camera
(1) Installation wrench
(4) Phillips head screws
(4) Plastic anchors
Features
-Max. 20fps@5MP
Built-in mic (-A)
CVI/CVBS/AHD/TVI switchable
Max. IR length 30m, Smart IR
IP67, DC12V
TECHNICAL SPECIFICATIONS:
Image Sensor: 1/2.7 inch CMOS
Image Size: 2592 (H)1944 (V), 5MP
Electronic Shutter: PAL: 1/25s-1/100000s NTSC: 1/30s-1/100000s
Minimum Illumination: 0.02Lux/F1.85, 30IRE, 0Lux IR on
IR LEDs: 1
Smart IR: Support
IR On/Off Control: Auto/ Manual
Focal Length: 2.8mm; 3.6mm
Angle of View H: 113, V:60
Max. Aperture: F1.85/F2.0
Close Focus Distance: 1.3m(4.27ft)
DORI Distance:
2.8mm: Detect: 56m (184ft) Observe: 22m (72ft); Recognize: 11m (36ft) Identify: 6m (20ft);
3.6mm: Detect: 80m (262ft) Observe: 32m (105ft) Recognize: 16m (52ft), Identify: 8m (26ft)
Video Resolution
5M (25921944); 4M (25601440); 1080P (19201080);960H (960 576/960480)
Video Frame Rate
CVI:
PAL: 5M@20fp; 4M@25fp; 1080P@25fp
NTSC: 5M@20fp; 4M@30fp; 1080P@30fp
AHD:
PAL: 5M@20fp; 4M@25fp; 1080P@25fp
NTSC: 5M@20fp; 4M@30fp; 1080P@30fp
TVI:
PAL: 5M@20fp; 4M@25fp; 1080P@25fp
NTSC: 5M@20fp; 4M@30fp; 1080P@30fp
CVBS:
PAL: 960H
NTSC: 960H
Day / Night: Auto switch by ICR
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto; manual
Gain Control: Auto/Manual
Digital Noise Reduction: 2D NR
Motion Detection: Off / On (4 Zone, Rectangle)
Certifications: CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Power Supply: 12V30% DC
Power Consumption: Max 3.7W (12V DC, IR on)
Operating Temperature: -40C to +60C (-40F to +140F); =less than 95% (non- condensaon)
Storage Temperature: -40C to +60C (-40F to +140F); less than 95% (non- condensaon)
Ingress Protection: IP67
Dimensions:
97.0mm85.8mm (3.82″3.38″)
.
Weight:
Net Weight 0.22kg (0.49lb)
Gross Weight 0.28kg (0.62lb)
