5MP HDCVI 1/2.8 IR-Fisheye Camera, Smart IR, Starlight, True WDR HCC5451

Description

• 5MP HDCVI IR-Fisheye Camera The 5MP HDCVI fisheye camera adopts a panoramic fisheye lens and high-performance image sensor, as well as a 10m IR range, enabling a full overview and superior image details with 5MP resolution.
• That makes it easy to collect evidence at any time for effective playback and analysis.
• Its panoramic view and 5MP resolution make the camera an ideal choice for large size businesses and places such as airports, stadiums, parking lots, and shopping malls.
• Camera Image Sensor 1/2.8″ 5MP CMOS
• Effective Pixels 2592(H)1944(V),5MP

5MP HDCVI 1/2.8 IR-Fisheye Camera, Smart IR, Starlight, True WDR HCC5451

5MP HDCVI IR-Fisheye Camera The 5MP HDCVI fisheye camera adopts a panoramic fisheye lens and high-performance image sensor, as well as a 10m IR range, enabling a full overview and superior image details with 5MP resolution. That makes it easy to collect evidence at any time for effective playback and analysis. With the use of advanced algorithms, more than 10+ dewarping modes are available on the XVR (select models) and mobile client. Its panoramic view and 5MP resolution make the camera an ideal choice for large size businesses and places such as airports, stadiums, parking lots, and shopping malls.

Key Features:

1/2.8 5Megapixel progressive scan CMOS

– Max. 20fps@5MP

– Built-in Mic

– 120db true WDR, Starlight, 2D&3D NR

– Max. IR length 10m, Smart IR

– DC12V

Specifications:

Camera Image Sensor 1/2.8″ 5MP CMOS

Effective Pixels 2592(H)1944(V),5MP

Scanning System Progressive

Electronic Shutter Speed PAL:1/4s~1/100,000s NTSC:1/3s~1/100,000s

Minimum Illumination 0.005Lux/F2.0 (Color), 30IRE,0lux IR on

S/N Ratio More THan 65dB

IR Distance 10m

IR On/Off Control Auto (ICR)/Color/B/W

IR LEDs 3

Lens

Lens Type Fixed lens / Fixed iris

Mount Type Board-in

Focal Length 1.4mm

Max Aperture F2.0

Angle of View H: 180, V:180

Focus Control N/A

Close Focus Distance 0.2m(7.87”)

DORI

Distance Note: The DORI distance is a general proximity of distance which makes it easy to pinpoint the right camera for your needs. The DORI distance is calculated based on sensor specification and lab test results according to EN 62676-4 which defines the criteria for Detect, Observe, Recognize and Identify respectively.

DORI DEFINITION DISTANCE

Detect 25pz/m (8px/ft) 28m (92 ft)

Observe 63px/m (19px/ft) 12m (37 ft)

Recognize 125px/m (38px/ft) 6m (18ft)

Identify 250ppm (76px/ft) 3m (9ft)

Pan/Tilt/Rotation

Pan: NA

Tilt:NA

Rotation: N/A

Video

Video Resolution: 5MP (25921944)

Frame Rate: 20fps@5MP,25/30fps@4MP

Video Output: 1-channel BNC high definition video output.

Day/Night: Auto (Electronic) / Manual

OSD Menu: Multi-Language

BLC Mode: BLC / HLC / WDR

WDR: 120dB

Gain Control: AGC

Noise Reduction: 2D/3D

White Balance: Auto / Manual

Smart IR: Auto / Manual

Certifications

CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Interface

Audio Built-in mic

Electrical

Power Supply DC12V 30%

Power Consumption 7.3W (IR ON)

Environmental

Operating Conditions -30C ~ +60C (-22F ~ +140F) / Less than 95% RH * Start up should be done at above-30C (-22F)

Storage Conditions -30C ~ +60C (-22F ~ +140F) / Less than 95% RH

Ingress Protection & Vandal Resistance N/A

Construction

Casing Aluminium + Plastic

Dimensions 126.2mm x 40.6mm(4.97″x 1.6″)

Net Weight 0.24kg (0.53lb)

Gross Weight 0.42kg (0.93lb)
