3.75″ 60W RMS 4-Ohm Water Resistant Marine Tweeters Pair DS18 NXL-T1

Description

3.75″ 60W RMS 4-Ohm Water Resistant Marine Tweeters Pair DS18 NXL-T1

This Listing Includes:

• (2) 3.75″ Tweeters
• (2) Tweeter enclosures
• (1) Set of Mounting Hardware & Wires

Description:

Experience exceptional sound quality even in the harshest conditions with DS18’s NXL-T1 Marine Super Bullet Tweeter. Engineered with 100% waterproof construction, this tweeter is built to withstand water and moisture, ensuring long-lasting performance without any damage or corrosion. Whether used with or without the included enclosure, its compact size allows for easy mounting in various applications, making it ideal for 4×4 vehicles, marine systems, and motorcycles. Delivering crystal-clear highs, the NXL-T1 features a 1″ aluminum voice coil and 240W of MAX power handling. With a sensitivity rating of 103dB and a frequency response of 3KHz-20 KHz, this tweeter guarantees enhanced audio performance like never before. Its marine-grade materials and UV & salt protection ensure durability, featuring an ASA body material, Kapton voice coil former, and aluminum diaphragm.

Download Owner’s Manual

GENERAL SPECIFICATIONS:

• Nominal Diameter: 3.75″
• Nominal Impedance: 4 OHMS
• AES Power Handling: 60W
• Program Power Handling: 120W
• Peak Power Handling: 240W
• Sensitivity (1w/1m): 103dB
• Frequency Response: 3Khz-20 KHz
• Recommended Hi Pass Crossover: 2 KHz
• Marine Grade Type: IP36
• UV & Salt Protection: Yes

MOTOR SPECIFICATIONS:

• Voice Coil Diameter: 1″
• Voice Coil Former: Material Kapton
• Winding Material: CCAW
• Diaphragm Material: Aluminum
• Magnet Material: Ferrite
• Magnet Weight: 8 Oz
• Body Material: ASA

MEASUREMENTS:

• Overall Diameter 3.78″
• Overall Depth 1.78″
• Front Mount Baffle Cutout 2.72″
• Mounting Depth 1.57″

MEASUREMENTS:(WITH ENCLOSURE)

• Overall Diameter 3.78″
• Overall Depth 2.26″
