2x 6.5 Mid range X6.4BM Loud speakers TW220 Super Tweeter set DS18 Pro Audio

Description

2x 6.5 Mid range X6.4BM Loud speakers TW220 Super Tweeter set DS18 Pro Audio

This listing includes:

(2) 6.5″ PRO-X6.4BM speakers

(2) TW220 Super Tweeters

Specifications Per PRO-X6.4BM Speakers:

Nominal Diameter: 6.5″ (165.1 mm)

Nominal Impedance: 4 ohm

RMS Power Handling: 250 Watts

MAX Power Handling: 500 Watts

Sensitivity (1W/1M): 94 dB

Frequency Response: 125Hz-12KHz

Recommended Hi Pass Crossover: 120 Hz

Midrange:

Voice Coil Diameter: 1.5″ (38.1 mm)

Voice Coil Material: Kapton

Winding Material: CCAW

Basket Material: Steel

Magnet Material: Ferrite

Magnet Weight: 30 oz

DIMENSIONS:

Overall Diameter: 6.61 (168 mm)

Front Mount Baffle Cutout: 5.7″ (145 mm)

Mounting Depth: 2.44″ (62 mm)

Overall Depth: 2.72 (69 mm)

Specifications Per TW220 Tweeter

Nominal Diameter: 3.2 (81 mm)

Nominal Impedance: 4 Ohm

MAX Power Handling: 240 Watts

RMS Power Handling: 120 Watts

AES Power Handling: 60 Watts

Sensitivity (1w/1m): 104 dB

Frequency Response: 2kHz ~ 20kHz

Recommended HI Pass Crossover: 3kHz

MOTOR:

Voice Coil Diameter: 1 (25.4mm)

Voice Coil Former Material: Kapton

Winding Material: CCAR

Diaphragm Material: Aluminum

Magnet Material: Ferrite

Magnet Weight: 8 Oz

BODY SPECIFICATIONS:

Bullet Material: Aluminum

Body Material: Aluminum

Body Color/Finish: Sandblasted Black

DIMENSIONS PER TWEETER:

Overall Diameter: 3.2 (81mm)

Front Mount Baffle Cutout: 2.83 (72mm)

Overall Depth: 2.57 (65.4mm)

Mounting Depth: 2.3 (58.4mm)

Weight: 1.4 lbs
