1500W RMS 1-Ohm Stable Monoblock Class-D Amplifier ORION XTR Series XTR1500.1DZ

Description

• Advanced Protection Measures – Equipped with protection circuitry, the amplifier safeguards against overheating and short circuits, ensuring durability.
• Compact and Stylish Design – The amplifier’s compact design offers versatile installation options without compromising performance or aesthetics.
• 1500 Watts RMS – Immerse yourself in a world of sonic excellence with 1500 Watts RMS, delivering unprecedented audio performance.
• Class D Amplification – Experience the pinnacle of efficiency and precision with Class D amplification for commanding and accurate sound reproduction.
• Precision Audio Control – The adjustable built-in crossover allows meticulous calibration of audio frequencies, optimizing speaker performance.

1500W RMS 1-Ohm Stable Monoblock Class-D Amp w/ Bass Knob Orion XTR1500.1DZ

This Listing Includes:

• (1) Monoblock Class-D Amplifier ORION XTR Series XTR1500.1DZ

Description:

Unleash Auditory Excellence:

The ORION XTR1500.1Dz XTR Series 1500W RMS 1-Channel Class-D Amplifier redefines audio supremacy. With advanced features and precision engineering, this amplifier transcends conventional boundaries, delivering an unrivaled fusion of power, accuracy, and control to your car audio system.

Immersive Sound Reproduction

Immersive Sound Reproduction: Rediscover your music in exquisite detail. Every note, beat, and melody from the softest to the most intense is faithfully reproduced for an immersive and authentic listening experience.

Unprecedented Power and Precision

Experience your music with an unprecedented level of power and precision. The ORION XTR1500.1Dz XTR Series Amplifier seamlessly blends commanding power with exceptional audio quality, crafting a sonic masterpiece that resonates deeply.

Elevate Your Drive

Step into a realm of sonic magnificence with the ORION XTR1500.1Dz XTR Series 1500W RMS 1-Channel Class-D Amplifier. Elevate your audio journey, redefine your driving soundtrack, and immerse yourself in an elevated level of musical sophistication. It’s time to embrace sound in its purest form.

Features:

• All MOSFET Power Supply & Output Stage
• Heavy Gauge / High Current Custom Power and Speaker Terminals
• 12dB Octave Low-Pass Filter
• Remote Gain Controller Included
• Electronic Crossover Network
• Bass Boost Circuit
• Power and Protection LED Indicators
• Soft Turn-on/Turn-off Turn-On Delay
• Fault and Protection Monitoring
• 4-Way Protection: Thermal, DC offset, Short Protection, under & over voltage

Specifications:

• RMS Power @ 4 Ohms @ 0.5% THD+N: 750W
• RMS Power @ 2 Ohms @ 0.5% THD+N: 1050W
• RMS Power @ 1 Ohm @ 0.5% THD+N: 1500W
• Linked with identical Amplifier
• RMS Power @ 2 Ohms @ 0.5% THD+N: 3000W
• Positive Terminals: 1 x 0 AWG.
• Negative Terminals: 1 x 0 AWG.
• Remote Turn-ON Signal: 10 AWG.
• Speaker Output Terminals: 4 AWG.
• Frequency Response: 20Hz – 250Hz
• Low Pass Crossover: 30Hz – 300Hz
• Supply Voltage: 9 – 16V
• Amplifier Efficiency: >88%
• Damping Factor: 200dB
• Signal to Noise Ratio: >90dB
• T.H.D. & Noise: 0.5%
• Phase Shift: 0 – 180
• Bass Boost: 0-18dB Variable
• Subsonic Filter: Off / 25Hz
• Variable Input Level Control: 0.2V – 6.0V
• Fuses: 150A recommended (not included)
• Dimensions (L x W x H): 11.42″ x 9.25″ x 2.75″ (290x235x70mm)
