10″ 250W RMS 4-Ohm SVC Subwoofer Kicker CompC Series / 50CWCS104

Description

10″ 250W RMS 4-Ohm SVC Subwoofer Kicker CompC Series / 50CWCS104

This Listing Includes:

• (1) 50CWCS104 Subwoofer

Description:

The 10″ 250W RMS 4-Ohm SVC Subwoofer Kicker CompC Series / 50CWCS104 delivers powerful bass and exceptional sound quality, making it a must-have for any car audio enthusiast. With its robust construction and high-performance capabilities, this subwoofer is designed to provide deep, resonant lows that elevate your music experience. The CompC Series is known for its durability and reliability, ensuring long-lasting performance even under heavy use. This subwoofer’s compact design allows for easy installation in a variety of vehicles, making it a versatile choice for any car audio setup. Upgrade your sound system with the Kicker CompC Series subwoofer and enjoy an unparalleled listening experience.

Download Owner’s Manual

Features:

• Single Four-Ohm Voice Coil and Reengineered for Increased Excursion and Deeper Bass
• Injection-Molded Polypropylene Cone
• Forced-Air Cooling for Outstanding Durability
• Ribbed Polyurethane Surround
• Signature Yellow Surround Stitching
• High-Strength Spiralead Tinsel Leads
• Stamped Steel Basket
• High Temp Voice Coil
• Spring-Loaded Speaker Terminals

Specifications:

• Size [in, cm]: 10, 25
• Recommended Amplifier Power [watts RMS]: 125-250
• Peak Power Handling [watts, per ANSI/CTA-2031-A]: 500
• Sensitivity [dB 1w/1m]: 85.9
• Rated Impedance [OHMS]: 4 SVC
• Fs [Hz]: 33.9
• Frequency Response [Hz]: 30-500

Thiele & Small Parameters:

Electrical Parameters

• Re: 3.775 | Ohm | electrical voice coil resistance at DC
• Krm: 0.0031 | Ohm | WRIGHT inductance mode
• Erm: 0.93 | WRIGHT inductance mode
• Kxm: 0.02235 | Ohm | WRIGHT inductance mode
• Exm: 0.78 | WRIGHT inductance mode
• Cmes: 867.8 | F | electrical capacitance representing moving mass
• Lces: 30.625 | mH | electrical inductance representing driver compliance
• Res: 48.48 | Ohm | resistance due to mechanical losses
• fs: 30.95 | Hz | driver resonance frequency

Mechanical Parameters

• Mms: 96.9255 | g | mechanical mass of driver diaphragm assembly including air load and voice coil
• Mmd(Sd): 89.217 | g | mechanical mass of voice coil and diaphragm without air load
• Rms: 2.305 | kg/s | mechanical resistance of total-driver losses
• Cms: 0.274 | mm/N | mechanical compliance of driver suspension
• Kms: 3.66 | N/mm | mechanical stiffness of driver suspension
• Bl: 10.5685| Tm | force factor (Bl product)

Loss Parameters

• Qtp: 0.6495 | total Q-factor considering all losses
• Qms: 8.1655 | mechanical Q-factor of driver in free air considering Rms only
• Qes: 0.6365 | electrical Q-factor of driver in free air considering Re only
• Qts: 0.59 | total Q-factor considering Re and Rms only

Other Parameters

• Vas: 15.1976 | I | equivalent air volume of suspension
• n0: 0.2235 | reference efficiency (2 pi-radiation using Re)
• Lm: 85.69 | dB | characteristic sound pressure level (SPL at 1m for 1W @ Re)
• Lnom: 85.945 | dB | nominal sensitivity (SPL at 1m for 1W @ Zn)
• Sd: 359.68 | sq cm | diaphragm area
• Xmax: 13.15 | mm

Measurement:

• Outer Frame Dimension [in, cm]: 10-11/16, 27.2
• Mounting Depth [in, cm]: 5-3/16, 13.2
• Mounting Cutout [in, cm]: 9-3/16, 23.3

Enclosure Suggestions:

• Max Rec Sealed Box Vol [cu. ft, liters: 2.4, 68
• Min Rec Sealed Box Vol [cu. ft, liters: 1, 28.3
• Max Rec Vented Box Vol [cu. ft, liters): 1.75, 49.6
• Min Rec Vented Box Vol [cu. ft, liters]: 1.25, 35.4
