10″ 2 Ohm 1750W RMS V.2 Dual Voice Coil Subwoofer Sundown U-Series U-10-D2-V2

Description

• Stitched-on double-XL tinsel leads
• Solid pole with vent channels and aluminum shorting ring cap
• Innovative high-velocity cast aluminum vented frame spacer ring
• Black Aluminum 3″ voice coil former for superior heat dissipation
• Double stitched surround

10″ 2 Ohm 1750W RMS V.2 Dual Voice Coil Subwoofer Sundown U-Series U-10-D2-V2

This listing includes:

• (1) 10″ 2 Ohm 1750W RMS V.2 Dual Voice Coil Subwoofer Sundown U-Series U-10-D2-V2

Description:

Designed to be at home in the competition lanes or playing your favorite music, the U Series is the premier standard suspension woofer in the Sundown lineup. A double-stacked 9.4-inch-wide ferrite magnet system is coupled to a thick top plate. A thick set of shorting rings are used inside the magnets and on the pole cap, smoothing out frequency response while doubling as a heat sink and airflow guide. A custom, substantially thicker aluminum frame was designed specifically for the U Series, equipped with heat dissipation ribs. The U v.2 motor also features an extended pole piece to keep the coil under perfect control under high stress. The coil temperature is kept in check via a high-velocity solid pole / machined pole channels arrangement and a series of 16 direct air-gap vents in the back plate.

Features:

• Black Aluminum 3″ voice coil former for superior heat dissipation
• High Temperature Round-Wire ALU voice coil with high-temp black adhesive
• Double stitched surround
• Heavy duty cast baskets – all new, custom-tooled
• Spring loaded terminals accept up to 8 gauge
• Stitched-on double-XL tinsel leads
• Solid pole with vent channels and aluminum shorting ring cap
• Rear drilled gap-venting
• Innovative high-velocity cast aluminum vented frame spacer ring
• Magnet ID shorting ring
• Top-Plate Cooling Channels
• Cast Aluminum surround bolt-on rings
• Optimized for small ported or bandpass enclosures

Specifications:

• RE (Ohms): 3.918
• FS (Hz): 49.9826
• VAS (L): 5.6312
• Qes: 0.5327
• Qms: 4.4138
• Qts: 0.4753
• Le (mH): 3.1056
• BL (NA): 26.5116
• Mms (Grams): 304.2236
• Cms (uM/N): 33.3280
• Sens (dB @ 1w/1m): 82.9533
